BUSSMANN CHCC3DU 3P 10×38 Rail Fuse Holder Base | 690V 32A DIN Mount
Overview
The BUSSMANN CHCC3DU is a premium 1-pole fuse holder designed for DIN rail mounting in industrial and commercial electrical systems. Engineered to accommodate 10×38 mm fuse cartridges, this component ensures secure installation and reliable protection for circuits operating up to 600V AC/DC and 30A. Manufactured by Eaton's Bussmann division—a globally recognized leader in circuit protection—this fuse holder adheres to stringent international safety and performance standards.
Key Features
1. High Voltage & Current Rating
- Rated for 600V AC/DC and 30A continuous operation, making it suitable for demanding applications in control panels, power distribution units, and machinery.
2. Robust Construction
- Constructed from flame-retardant thermoplastic (UL94 V-0 rated) with corrosion-resistant brass alloy contacts, ensuring durability in harsh environments.
3. DIN Rail Compatibility
- Effortless snap-on installation on standard 35mm DIN rails (EN 60715), reducing assembly time and eliminating the need for additional mounting hardware.
4. Secure Fuse Retention
- Positive-lock design with screwless terminal clamps guarantees vibration-resistant fuse seating, preventing accidental disconnection.
5. Transparent Cover
- Integrated polycarbonate window allows visual verification of fuse integrity without disassembly, facilitating rapid maintenance checks.
Technical Specifications
| Parameter | Specification |
|---------------------|----------------------------|
| Fuse Type | 10×38 mm (IEC/DIN) |
| Poles | 1 |
| Voltage Rating | 600V AC/DC |
| Current Rating | 30A |
| Mounting | DIN Rail (35mm) |
| Contact Material| Silver-plated Brass |
| Insulation | UL94 V-0 Thermoplastic |
| Compliance | IEC/EN 60269, UL 508 |
Applications
- Motor control centers
- HVAC systems
- Renewable energy inverters
- Industrial automation cabinets
- Power supply units
Safety & Reliability
Each CHCC3DU unit undergoes rigorous quality validation, including dielectric strength testing (2,500V AC) and thermal cycling. The design prevents accidental contact with live parts and includes finger-safe terminals compliant with IEC/EN 60204-1.
Optimize your electrical protection strategy with Bussmann’s engineered solutions. Order the CHCC3DU today to enhance system safety and reduce downtime.
