| ENCODER RHI 503 |
| PART NO 519858-10 |
| SER NO 48677236 |
| SUPPLY 9-30 VDC |
| OUTPUT 360PPRHTL |
outputABZThe counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.
Signal output: RS422 - long-line drive output, push-pull output, NPN collector open circuit.
Parameters: Pulse number 10 cpr-2048 CPR is optional,Working voltage DC5V-30V power supply, maximum mechanical speed 15000 rpm, response frequency: 0-300KHz, consumption current: <150MA.
Output:output circuitYesNPN(PNP)Open-circuit output type of collector"Voltage type, complementary type and long-line driving type（RS422)
Purpose:Servo motors, servo motors, CNC machine tools, door machines, pipe benders, textile equipment, elevators, etc.
