Encoder RHI594 1024 PPRGerman Technical Encoder
Part no: 630409-02 output 1024 PPR HTL
outputABZThe counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.
Integral structure, easy to install, shaft aperture:08-10-12-14-15-16
Parameters: Pulse number 10 cpr-5000 CPR is optional,Working voltage DC5V-30V power supply, maximum mechanical speed 15000 rpm, response frequency: 0-300KHz, consumption current: <150MA.
Output:The output circuit hasNPN(PNP) collector open-circuit output typevoltage type,complementary type and long-line drive type（RS422)
Purpose:Servo motors, CNC machine tools, elevators, door machines, pipe benders, textile equipment
