TVI40N-09TK0T6TN-00360 New German TechnologyEncoder
outputABZ. The counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.
Outside diameter:50mmAxis diameter:5-6-8-10mmEncoder bodyTightening flange andSynchronized flange fixing;
pulse10-1500Signal output:TLLandHTLoutputRS422
Voltage:DC5V,10V-30V;
Parameters: The number of pulses is optional.DC5V-30V power supply, maximum mechanical speed 12000 rpm, response frequency: 0-300KHz, consumption current: <150MA.
Output:The output circuit hasNPN(PNP collector open-circuit output typevoltage type,complementary type and long-line drive type（RS422)General type
Purpose:Servo Motor, CNC Machine Tool, Elevator, Door Machine
