8.Five020.2322.Five000 New modelGerman TechnologyEncoder
outputABZ generates direction-recognizable counting pulses by rotating grating discs and optocouplers.
axis/aperture: 6.35-08-10-12-14-15MM
Parameters: Number of pulses2cpr-5000cprOptional,working voltageDC5V-30Vpower supply,Maximum mechanical speed5000 rpm, response frequency: 0-300 KHz, consumption current: <150MA.
Output:output circuitYesNPN(PNP)Open-circuit output type of collector\ Voltage type, complementary type and long-line driving type（RS422)
Purpose:Servo motors, CNC machine tools, elevators, door machines, pipe benders, textile equipment
