FTE-A/35AC10-30F1024BBrand newParagraph emptySpindle encoder
The counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.
Universal rotary encoder,ABZ three-phase. The counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.
Parameters: The number of pulses is optional.DC5-26V power supply, can do 12-24V power supply. Maximum mechanical speed 8000 rpm, response frequency: 0-300KHz, consumption current: <150MA.
Output:output circuitYesNPN(PNP)Open-circuit output type of collector\ Voltage type, complementary type and long-line driving type（RS422)General type(Note: When the collector is not connected with pull-up resistance, there is no voltage output)
Purpose:Elevator.,Machine tool spindle,CNCProcessing centers, engraving and milling machines, engraving machines, gantry milling, etc.
