EC50W10-C4AR-1000New Swiss TechnologyHollow shaft encoder
outputABZ A-B-Z-。 The counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.
Parameters: The number of pulses is optional.DC5VPower supply, maximum mechanical speed 12000 rpm, response frequency: 0-300KHz, consumption current: <120MA.
Output:The output circuit hasNPN(PNP) collector open-circuit output typevoltage type,complementary type and long-line drive type（RS422)(Note: There is no voltage output when the collector is not connected with pull-up resistance)
Purpose:Servo Motor, CNC Machine Tool, Elevator, Door Machine, Machining Center
