SZB30C-102FourRF-30JComplete replacement of elevator encoder
outputABZ。 The counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.
2Number of pulses100-200-.512.600-1024.4096-5400p/r
4Output Form:Open collector output, push-pull output, long-line drive output
The encoder body is fixed by shrapnel.
use Path: Asynchronous Elevator Speed Control and Industrial Automation Control
Excellent Point: Stable performance, strong anti-interference
Parameters: The number of pulses is optional.DC5V-30VPower supply, maximum mechanical speed 8000 rpm, response frequency: 0-300KHz, consumption current: <150MA.
Output:The output circuit hasNPN(PNP) collector open-circuit output typevoltage type,complementary type and long-line drive type（RS422)General type
Purpose:Servo Motor, CNC Machine Tool, Elevator, Door Machine
