ERN 420 2048 01-03 Id.Nr.31Five 142-30GermanyHEncoderComplete substitutes
outputABZ generates direction-recognizable counting pulses by rotating grating discs and optocouplers.
Axle aperture:08-10-12-14-15
Parameters: Number of pulses5Cpr-Thirty-six00cprOptional,working voltageDC5V-30Vpower supply,Maximum mechanical speed5000 rpm, response frequency: 0-300 KHz, consumption current: <150MA.
Output:output circuitYesNPN(PNP)Open-circuit output type of collector\ Voltage type, complementary type and long-line driving type（RS422)
Purpose:Servo motors, CNC machine tools, elevators, door machines, pipe benders, textile equipment
