ZKPThirty-eight08-006G-360B-12-24CReapREPHeadHEDSSEncoder.outputABZThe counting pulse signal of identifiable direction is generated by rotating grating disc and optocoupler.
external diameter38Axis aperture:8,Shaft holding structure, not easy to loosen
Parameters: Pulse number 10 cpr-5000 CPR is optional,Working voltage DC5V-30V power supply, maximum mechanical speed 15000 rpm, response frequency: 0-300KHz, consumption current: <150MA.
Output:output circuitYesNPN(PNP)Open-circuit output type of collector"Voltage type, complementary type and long-line driving type（RS422)General type(Note: When the collector is not connected with pull-up resistance, there is no voltage output)
Purpose:Servo motors, CNC machine tools, elevators, door machines, pipe benders, textile equipment
